5.6 Net data (PKW and PZD area)
5-253
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
 Error code
Table 5-24 Fault code in Gx_XIST2
Gx_XIST2
Meaning Possible causes/description
1
hex
Encoder sum error The fault description should be taken from the following faults (refer
to Chapter 7.3.2):
 Fault 514 Motor measuring system (encoder 1)
 Fault 609 Encoder limiting frequency exceeded
 Fault 512 Direct measuring system (encoder 2)
 Fault 615 DM encoder limiting frequency exceeded
2
hex
Zero mark monitoring The fault description should be taken from the following faults (refer
to Chapter 7.3.2):
 Fault 508 Motor measuring system (encoder 1)
 Fault 514 Direct measuring system (encoder 2)
3
hex
Abort parking encoder The ”parking axis” was already selected.
4
hex
Abort, reference mark
search
 A fault is present (Gx_ZSW.15 = 1)
 Parking encoder/axis active
 ”Flying measurement” function already active
 Change of function type
 No reference marker programmed
 Hardware already busy with another function
 Only BERO: BERO not at terminal I0.x
 Not BERO: EnDat encoder used
 Invalid combination of reference markers for distance–coded
encoder (1–2, 3–4, 1–2–3–4 are supported)
5
hex
Retrieve reference
value interrupted
 A fault is present (Gx_ZSW.15 = 1)
 Parking encoder/axis active
 No reference marker programmed
 Requested value not available
 Change of function type
6
hex
Abort, flying measure-
ment
 A fault is present (Gx_ZSW.15 = 1)
 Parking encoder/axis active
 Change of function type
 Reference point approach still active
 Measuring probe not at terminal I0.x and measuring probe 1 not
used
 Hardware already busy with another function
 Spindle positioning active (P0125=1, from SW 5.1)
7
hex
Abort, retrieve mea-
sured value
 A fault is present (Gx_ZSW.15 = 1)
 Parking encoder/axis active
 Change of function type
 Requested value not available
 Not exactly 1 value to be retrieved
8
hex
Abort absolute value
transmission on
 EnDat encoder not used
