5.7 Settings at the PROFIBUS DP master
5-283
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
For the parameterizing data, the following should be noted:
for DP slaves with SIEM8055.GSD
The drive only expects the 6–byte standard DP parameterizing tele-
gram.
for DP slaves with SIEM808F.GSD (from SW 3.1)
– If there is no clock–synchronous operation
The standard setting from the GSD can be used for the parame-
terizing data.
– If there is clock–synchronous operation
The parameterizing data must, in some cases, be modified (refer
to Chapter 5.8.5).
The following must be observed for the configuration data:
for DP slaves with SIEM8055.GSD
Using the configuration telegram, the ”DP slave 611U” is signaled
the PPO type, the axis number and consistent or inconsistent data
transfer mode.
A consistent data transfer is selected as standard via the GSD file.
The ”DP slave 611U” also accepts an inconsistent data transfer (re-
fer to Table 5-33).
Consistent and inconsistent entries can also be mixed (e.g. the
PKW area with consistent and the PZD area with inconsistent data
transfer).
Table 5-33 Permissible configuration telegrams
Data transfer
PPO
Consistent
(over the complete length)
Inconsistent
(consistent over 1 word)
1–axis 2–axis 1–axis 2–axis
1 F3F1 F3F1F3F1 7371 73717371
2 F3F5 F3F5F3F5 7375 73757375
3 F1 F1F1 71 7171
4 F5 F5F5 75 7575
5 F3F9 F3F9F3F9 7379 73797379
Parameterizing
telegram
Configuration
telegram
5 Communications via PROFIBUS DP
