5.7 Settings at the PROFIBUS DP master
5-290
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Faults which occur are entered into a fault buffer. The fault code, fault
number, fault time and fault value for each fault are specified using the
appropriate parameters.
The ”SIMODRIVE 611 universal” drive signals as to whether there is at
least one fault using the status bit or output signal ZSW1.3 ”Fault pre-
sent/no fault present”.
The fault buffer comprises 8 fault cases, each of which can include 8
fault entries.
For fault case 1, the faults which have occurred are saved and they
remain there until the fault case has been removed, i.e. all of the faults
have been removed and also acknowledged.
In fault cases 2 to 8, the acknowledged fault cases since the last
POWER ON are saved. The number of fault cases since POWER ON
can be read from P0952.
Index 0 No significance
1 101 2 t_101 w_101
2 114 10 t_114 w_114
30 0 0 0
40 0 0 0
50 0 0 0
60 0 0 0
70 0 0 0
80 0 0 0
9 90 3 t_90 w_90
100000
to to
160000
to
570000
580000
to to
640000
P0947:65
Fault number
P0945:65
Fault code
P0948:65
Fault time
P0949:65
Fault value
Fault
case
1
Fault
case
2
Fault
case
8
to
Fig. 5-24 Fault buffer structure
Evaluating
faults via
PROFIBUS–DP
Status signal for
faults
Fault buffer
