6.1 Operating mode, speed/torque setpoint (P0700 = 1)
6-347
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Table 6-7 Parameters for speed limiting
Parameters
No. Description Min. Stan-
dard
Max. Units Ef-
fec-
tive
1146 Maximum motor speed (SRM)
Maximum motor speed (ARM)
Maximum motor velocity (SLM)
0.0
0.0
15000.0
0.0
100 000.0
RPM
RPM
m/min
PO
... specifies the maximum motor speed or maximum motor velocity defined by the motor
manufacturer.
Note:
This is only included in the speed limiting for rotary induction motors (ARM).
1147 Speed limit (SRM)
Speed limit (ARM)
Velocity limit, motor (SLM)
0.0
7 000.0
8 000.0
120.0
100 000.0
RPM
RPM
m/min
Im-
medi-
ately
... specifies the maximum permissible motor speed or motor velocity.
When commissioning the system for the first time and for ”calculate unlisted motors”, the param-
eter is pre–assigned as follows:
 SRM 1.1  P1400
1.05  P1400 (from SW 7.1 with ”SIMODRIVE 611 universal HR”,
resolver)
 ARM, SLM, PE spindle P1146
Speed actual value > Speed limit
 Exceeded by more than 2 %:
The torque limit when motoring is internally set to zero, the drive is prevented from acceler-
ating any further.
With the appropriate setting, the ”speed controller at its limit” monitoring can respond.
1401:8 Speed for max. useful motor speed (SRM,
ARM)
–100 000.0
0.0
100 000.0
RPM
Im-
medi-
Velocity for max. motor useful velocity
(SLM)
–100 000.0
0.0
100 000.0
m/min
medi-
ately
... limits the speed to the maximum useful motor speed.
The parameter is pre–set at the first start–up and for ”Calculate unlisted motor”:
 SRM P1400
 ARM, SLM, PE spindle P1146
Note:
P1401:8 is used for normalization for speed setpoints entered via analog inputs (refer to Chap-
ter 6.6).
1405:8 Monitoring speed, motor (SRM, ARM)
Monitoring velocity, motor (SLM)
100.0 110.0 110.0 %
Im-
medi-
ately
... specifies the maximum permissible setpoint as a percentage referred to P1401:8.
The parameter is pre–assigned as follows when the system is commissioned for the first time
and for ”calculate unlisted motor”:
 SRM 110 %
105 % (from SW 7.1 with ”SIMODRIVE 611 universal HR”, resolver)
