1.3 ”SIMODRIVE 611 universal” control board
1-42
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Table 1-4 Which optional modules can be used for the various software releases?
Case
Firmware release Optional module
DP1 DP2 DP3
1. A master configured software, generated
with GSD file siem808f.gsd, can be oper-
ated with
from SW 3.1 no yes yes
2. A master configured software, generated
with a GSD file siem8055f.gsd and P0875
= 2, can be operated with
before SW 4.1 yes yes yes
3. A master configured software, generated
with a GSD file siem8055f.gsd and P0875
= 2, can be operated with
from SW 4.1 no yes yes
4. A master configured application, gener-
ated using gsd file si02808f.gsd and
P0875 = 2 can be operated with
from SW 6.1 no yes yes
Note
Case 1 is for ”new” applications with the DP2, DP3 module.
Cases 2 and 3 are for series commissioning of drives using DP1
modules and for replacing a defective DP1 module by a DP2 module.
From SW 4.1, the DP1 module can no longer be used.
Reader’s note
Information regarding
Installing the optional module ––> refer to Chapter 2
The interface (X423) ––> refer to Chapter 2
The connection diagram and wiring/connection of the option module
––> refer to Chapter 2
Communications via PROFIBUS–DP ––> refer to Chapter 5
