6.4 Input/output terminals of the control board
6-501
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Table 6-48 Overview of the output signals
Operating
mode
Signal name, description Fct. No. n–set pos PROFIBUS bit
Inactive 0 x x –
| n
act
| < n
min
1 x x MeldW.2
Ramp–up completed 2 x x MeldW.0
| M | < M
x
3 x x MeldW.1
| n
act
| < n
x
4 x x MeldW.3
Motor overtemperature pre–warning 5 x x MeldW.6
Heatsink temperature pre–warning 6 x x MeldW.7
Variable signaling function 7 x x MeldW.5
Open–loop torque controlled mode – x – ZSW1.14
Integrator inhibit, speed controller – x x ZSW2.6
Parameter set
1st input/2
0
2nd input/2
1
3rd input/2
2
–
–
–
x
x
x
x
x
x
ZSW2.0
ZSW2.1
ZSW2.2
Motor 1 selected (from SW 2.4)
Motor 2 selected
Motor 3 selected
Motor 4 selected
11
12
13
14
x
x
x
x
–
–
–
–
–
–
–
–
Status, fixed speed setpoint (from SW 3.1)
1st output/2
0
2nd output/2
1
3rd output/2
2
4th output/2
3
15
16
17
18
x
x
x
x
–
–
–
–
–
–
–
–
n
set
= n
act
20
x – ZSW1.8
n
set
= n
act
20
x x MeldW.8
Spindle positioning on (from SW 5.1) 28 x – ZSW1.15
Warning present/no warning present 29 (from
SW 3.3)
x x ZSW1.7
DC link monitoring V
DC link
> V
x
30 x x MeldW.4
Fault present/no fault present 31 x x ZSW1.3
Status, controller enable 32 x x ZSW1.2
Ready or no fault 33 x x ZSW1.1
Parking axis selected 34 x x ZSW2.7
Open holding brake 35 x x ZSW2.5
Pulses enabled (from SW 3.1) 36 x x MeldW.13
Power module current not limited (from SW 3.1) 37 x x MeldW.10
Control via PROFIBUS (from SW 3.1) 38 x x PZD
”DIG_OUT”
