7.4 Commissioning functions
7-714
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
7.4.1 Function generator (FG)
Using the function generator:
The influence of the higher–level control loops can be specifically
disabled
The dynamic performance can be compared for coupled drives
A simple characteristic (traversing profile) can be selected as set-
point and repeated, without having to program a traversing program
The function generator generates various types of setpoints (square-
wave, staircase, delta, PRBS or sinusoidal), and enters this setpoint,
corresponding to the selected mode, as current setpoint, disturbing
torque or as speed setpoint.
!
Danger
If the function generator is active, then traversing motion is not
monitored.
The following must be observed when starting the function generator:
The function generator is started as follows
– Setting P1800 = 1
The function generator is immediately started.
– Setting P1800 = 2 (from SW 8.1)
The function generator is started in synchronism – e.g. for gantry
axes if, in the n–set mode, the PROFIBUS control word
STW1.8=1.
The following starting conditions and enable signals must be avail-
able:
Table 7-5 Starting conditions for the function generator
Starting conditions
Operating mode, FG
P1804
= 1
= 3 (only V/Hz oper-
ation)
Operating mode FG
P1804
= 2
= 3 (without V/Hz
operation)
Speed controlled
operation on
x
Controller enable x x
Pulse enable x x
Internal regenerative stop
inactive
x x
Ramp–function generator
enabled
x x
x: Start condition must be fulfilled
Overview
Starting the
function
generator
