7
7.6 Spare parts
7-730
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
7.5.3 Parameters for V/Hz operation
The following parameters are available for V/Hz operation
Table 7-10 Parameter overview for V/Hz operation
Parameters
No. Name Min. Stan-
dard
Max. Units Effec-
tive
1014 Activates V/Hz operation 0 0 1 – PO
... V/Hz operation for this drive is activated/de–activated.
= 1 V/Hz operation is activated
= 0 V/Hz operation is de–activated
1125 Ramp–up time 1 for V/Hz operation 0.01 5.0 100.0 s Imme-
diately
When V/Hz operation is activated, this is the time in which the speed setpoint is changed from
0 to the maximum motor speed (P1146).
1127 Voltage at f = 0 V/Hz operation (ARM) 0.0 2.0 20.0 V(pk) Imme-
diately
When V/Hz operation is activated, and at 0 frequency, the voltage which is output is increased
by the value in this parameter.
Note:
The parameter is preset when carrying–out the ”calculate controller data” function.
7.6 Spare parts
Table 7-11 Terminals for SIMODRIVE 611 universal
Designation
Terminals Item number Order No.
[MLFB]
X421 AS1, AS2 GWE–000000590513 6SY9907
X431 P24, M24,9 663,19 GWE–000000588343 6SY9908
X451, X452 56.x, 14.x, 24.x, 20.x, ... GWE–000000588293 6SY9910
X461, X462 (10 pin) A+.x, A–.x, B+.x, B–.x
X461, X462 (11 pin) A+.x, A–.x, B+.x, B–.x A5E0009717 6SY9913
X453, X454 A+.x, A–.x, B+.x, ...0
X441 75.x. 16.x, 15 GWE–000000588277 6SY9911
X422, X432 I4...I11, O4...O11 GWE–000000588285 6SY9912
Power connector, motor connec-
tion
6SY9904
Power connector, pulsed resistor 6SY9905
Parameter
overview
7 Fault Handling/Diagnostics
08.02
