A
A.3 List of motors
A-873
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
A.3.4 List of linear synchronous motors
Table A-8 Motor code for linear synchronous motors (SLM)
Order No.
Motor code v
max
F
max
(MLFB) P1102 [m/min] [N]
1FN1124–5xC7x–xxxx 3001 145 4850
1FN1184–5xC7x–xxxx 3002 145 7920
1FN1122–5xC7x–xxxx 3003 145 3250
1FN1126–5xC7x–xxxx 3004 145 6500
1FN1186–5xC7x–xxxx 3005 145 10600
1FN1244–5xC7x–xxxx 3006 145 10900
1FN1246–5xC7x–xxxx 3007 145 14500
1FN1122–5xF7x–xxxx 3021 200 3250
1FN1126–5xF7x–xxxx 3022 200 6500
1FN1124–5xF7x–xxxx 3023 200 4850
1FN1184–5xF7x–xxxx 3024 200 7920
1FN1186–5xF7x–xxxx 3025 200 10600
1FN1244–5xF7x–xxxx 3026 200 10900
1FN1246–5xF7x–xxxx 3027 200 14500
1FN1072–3xF7x–xxxx 3031 200 1720
1FN1076–3xF7x–xxxx 3032 200 3450
2  1FN1124–5AC7x–xxxx 3201 145 9700
2  1FN1184–5AC7x–xxxx 3202 145 15840
2  1FN1122–5xC7x–xxxx 3203 145 6500
2  1FN1126–5xC7x–xxxx 3204 145 13000
2  1FN1186–5xC7x–xxxx 3205 145 21200
2  1FN1244–5xC7x–xxxx 3206 145 21800
2  1FN1246–5xC7x–xxxx 3207 145 29000
2  1FN1122–5xF7x–xxxx 3221 200 6500
2  1FN1126–5xF7x–xxxx 3222 200 13000
2  1FN1124–5xF7x–xxxx 3223 200 9700
2  1FN1184–5xF7x–xxxx 3224 200 15840
2  1FN1186–5xF7x–xxxx 3225 200 21200
2  1FN1244–5xF7x–xxxx 3226 200 21800
2  1FN1246–5xF7x–xxxx 3227 200 29000
2  1FN1072–3xF7x–xxxx 3231 200 3440
Motor code for
linear
synchronous
motors (SLM)
A Lists
01.99
08.0108.01
