Siemens SIMOTICS T-1FW6 Configuration Manual

Technical data and characteristics
6.2 Data sheets and diagrams
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
459
Data sheet 1FW6290-xxB20-xxxx
Table 6- 54 1FW6290-xxB20-0Lxx, 1FW6290-xxB20-2Pxx
Technical data
1FW6290
Symbol
Unit
-xxB20-0Lxx
-xxB20-2Pxx
Boundary conditions
DC link voltage
U
DC
V
600
600
Water cooling inlet temperature
T
VORL
°C
35
35
Rated temperature of winding
T
N
°C
130
130
Data at the rated operating point
Rated torque
M
N
Nm
5760
5670
Rated current
I
N
A
95.8
121
Rated speed
n
N
rpm
67.9
90.3
Rated power loss
P
V,N
kW
11
11.1
Limit data
Maximum torque
M
MAX
Nm
10900
10900
Maximum current
I
MAX
A
212
272
Electric motor power at M
MAX
P
EL,MAX
kW
90.8
106
Maximum speed
n
MAX
rpm
213
273
Maximum speed at maximum torque
n
MAX,MMAX
rpm
36.9
49.9
Max. speed without VPM
n
MAX,INV
rpm
145
187
No-load speed
n
MAX,0
rpm
106
137
Torque at n = 1 rpm
M
0
Nm
6030
6030
Current at M
0
and n = 1 rpm
I
0
A
101
129
Thermal static torque
M
0
*
Nm
4310
4310
Thermal stall current
I
0
*
A
71.1
91.3
Physical constants
Torque constant at 20 °C
k
T,20
Nm/A
60.7
47.3
Voltage constant
k
E
V/(1000/min)
3670
2860
Motor constant at 20 °C k
M,20
Nm/(W)
0,5
69.6 69.4
Thermal time constant t
TH
s 180 180
No. of pole pairs
p
-
42
42
Cogging torque
M
COG
Nm
30.2
30.2
Stator mass
m
S
kg
188
188
Rotor mass
m
L
kg
73
73
Rotor moment of inertia
J
L
10
-2
kgm
2
546
546
Phase resistance of winding at 20 °C
R
STR, 20
Ω
0.253
0.155
Phase inductance of winding
L
STR
mH
5.35
3.25
