Page #479 background image
Electrical connection
8.3 System integration
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
477
Signal connection
Only fully-threaded plug connectors can be used to connect signals. SPEED CONNECT
connections are not compatible.
Power connection
Prefabricated cables with full thread plug connectors or SPEED-CONNECT plug connectors
can be used as follows to connect the power:
Table 8- 2 Compatibility
Cable at the motor with
Connecting cable with
Compatible
SPEED-CONNECT plug connectors
SPEED-CONNECT plug connectors
Yes
SPEED-CONNECT plug connectors Fully-threaded plug connectors Yes
For suitable cables, see Catalog.
Note
Remove the O
-ring from the SPEED CONNECT plug connector before connecting it to a
SPEED CONNECT mating plug connector.
For plug connections comprising SPEED CONNECT and full thr
ead plug connectors, the O-
ring is required to ensure that the connection is tight and resistant to vibration. Do not
remove the O
-ring if this combination is used.
Even if a SPEED CONNECT plug connector has been correctly connected to a full thread
plug c
onnector, a gap will remain between the connector and mating connector. Do not try to
eliminate this gap by tightening the connectors further. This could damage the plug
connector.
Requirements
The power unit is selected depending on the motor current at torque M
0
or according to
the maximum motor current.
The encoder system used must be harmonized with the particular application.
Note
Read the corresponding documentation about open
-loop and closed-loop control systems.
