Description of the motor
2.5 Selection and ordering data
1FW6 Built-in torque motors
48 Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
Order desig. /
Size
Rated torque
1)
M
N
in Nm
Max. torque
M
MAX
in Nm
Rated cur-
rent
1)
I
N
in A
Max. current
I
MAX
in A
Rated speed
2)
n
N
in rpm
Max. speed at
max. torque
2)
n
MAX,MMAX
in rpm
1FW6290-xxB11-2Pxx
3110
6280
114
272
165
90.4
1FW6290-xxB15-7Axx
4600
8570
60.7
133
51.3
26.6
1FW6290-xxB15-0Lxx
4480
8570
94.4
212
88.5
48.7
1FW6290-xxB15-2Pxx
4390
8570
118
272
117
64.9
1FW6290-xxB20-0Lxx
5760
10900
95.8
212
67.9
36.9
1FW6290-xxB20-2Pxx
5670
10900
121
272
90.3
49.9
1)
Water cooling with 35 °C intake temperature;
2)
speed and current values at converter DC link voltage U
DC
= 600 V
(regulated) / converter output voltage (rms value) U
a max
= 425 V (regulated)
Table 2- 7 Built-in torque motors: overview (part 2 of 2)
Order desig. / size
Rated power
loss
1)
P
V,N
in kW
External diameter
of stators
in mm
Internal diameter
of rotors
in mm
Length of
stator
in mm
Motor
mass
3)
in kg
Moment of inertia
of rotor J
L
in 10
-2
kgm
2
1FW6050-xxB03-0Fxx
0.769
159
64
89
3.08
0.139
1FW6050-xxB05-0Fxx
1.04
159
64
109
5.89
0.267
1FW6050-xxB07-0Fxx
1.27
159
64
129
7.91
0.39
1FW6050-xxB07-0Kxx
1.23
159
64
129
7.91
0.39
1FW6050-xxB10-0Kxx
1.6
159
64
159
11.4
0.488
1FW6050-xxB15-0Kxx
2.27
159
64
209
19.2
0.691
1FW6050-xxB15-1Jxx
2.27
159
64
209
19.2
0.691
1FW6060-xxB03-0Fxx
0.778
184
92
89
7.08
0.347
1FW6060-xxB05-0Fxx
1.06
184
92
109
9.94
0.665
1FW6060-xxB05-0Kxx
1.07
184
92
109
9.94
0.665
1FW6060-xxB07-0Fxx
1.32
184
92
129
12.5
0.904
1FW6060-xxB07-0Kxx
1.33
184
92
129
12.5
0.904
1FW6060-xxB10-0Kxx 1.79 184 92 159 16.2 1.21
1FW6060-xxB10-1Jxx 1.86 184 92 159 16.2 1.21
1FW6060-xxB15-0Kxx 2.48 184 92 209 22.4 1.72
1FW6060-xxB15-1Jxx
2.65
184
92
209
22.4
1.72
1FW6090-xxB05-0Fxx
2.2
230
140
90
9.2
1.52
1FW6090-xxB05-0Kxx 2.14 230 140 90 9.2 1.52
1FW6090-xxB07-0Kxx
2.72
230
140
110
12.2
2.2
1FW6090-xxB07-1Jxx
2.69
230
140
110
12.2
2.2
1FW6090-xxB10-0Kxx
3.52
230
140
140
17.2
3.09
1FW6090-xxB10-1Jxx
3.52
230
140
140
17.2
3.09
