Siemens SIMOTICS T-1FW6 Configuration Manual

Description of the motor
2.5 Selection and ordering data
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
49
Order desig. / size
Rated power
loss
1)
P
V,N
in kW
External diameter
of stators
in mm
Internal diameter
of rotors
in mm
Length of
stator
in mm
Motor
mass
3)
in kg
Moment of inertia
of rotor J
L
in 10
-2
kgm
2
1FW6090-xxB15-1Jxx
4.9
230
140
190
27.2
4.65
1FW6090-xxB15-2Jxx
4.99
230
140
190
27.2
4.65
1FW6130-xxB05-0Kxx
3.01
310
220
90
13.2
6.37
1FW6130-xxB05-1Jxx
3.03
310
220
90
13.2
6.37
1FW6130-xxB07-0Kxx
3.82
310
220
110
18.2
8.92
1FW6130-xxB07-1Jxx
3.81
310
220
110
18.2
8.92
1FW6130-xxB10-1Jxx
4.98
310
220
140
25.2
12.7
1FW6130-xxB10-2Jxx
5.1
310
220
140
25.2
12.7
1FW6130-xxB15-1Jxx
6.91
310
220
190
38.2
19.1
1FW6130-xxB15-2Jxx
6.91
310
220
190
38.2
19.1
1FW6150-xxB05-1Jxx
2.66
385
265
110
21.7
10.1
1FW6150-xxB05-4Fxx
2.64
385
265
110
21.7
10.1
1FW6150-xxB07-2Jxx
3.38
385
265
130
33.5
14.2
1FW6150-xxB07-4Fxx
3.34
385
265
130
33.5
14.2
1FW6150-xxB10-2Jxx
4.46
385
265
160
47.5
20.9
1FW6150-xxB10-4Fxx
4.4
385
265
160
47.5
20.9
1FW6150-xxB15-2Jxx
6.25
385
265
210
70.8
31.3
1FW6150-xxB15-4Fxx
6.17
385
265
210
70.8
31.3
1FW6160-xxB05-1Jxx
2.94
440
280
110
36.3
19
1FW6160-xxB05-2Jxx
2.95
440
280
110
36.3
19
1FW6160-xxB05-5Gxx
2.99
440
280
110
36.3
19
1FW6160-xxB07-1Jxx
3.69
440
280
130
48.3
25.8
1FW6160-xxB07-2Jxx
3.71
440
280
130
48.3
25.8
1FW6160-xxB07-5Gxx
3.75
440
280
130
48.3
25.8
1FW6160-xxB07-8Fxx 3.84 440 280 130 48.3 25.8
1FW6160-xxB10-1Jxx 4.82 440 280 160 66.3 36
1FW6160-xxB10-2Jxx
4.84
440
280
160
66.3
36
1FW6160-xxB10-5Gxx
4.89
440
280
160
66.3
36
1FW6160-xxB10-8Fxx
5.01
440
280
160
66.3
36
1FW6160-xxB10-2Pxx
4.89
440
280
170
66.3
36
1FW6160-xxB15-2Jxx
6.73
440
280
210
95.3
53.1
1FW6160-xxB15-5Gxx
6.8
440
280
210
95.3
53.1
1FW6160-xxB15-8Fxx
6.96
440
280
210
95.3
53.1
1FW6160-xxB15-2Pxx
6.8
440
280
220
95.3
53.1
1FW6160-xxB15-0Wxx
6.96
440
280
220
95.3
53.1
1FW6160-xxB20-5Gxx
8.7
440
280
260
124
70.1
1FW6160-xxB20-8Fxx
8.91
440
280
260
124
70.1
1FW6160-xxB20-2Pxx
8.7
440
280
270
124
70.1
1FW6160-xxB20-0Wxx
8.91
440
280
270
124
70.1
