Siemens SIMOTICS T-1FW6 Configuration Manual

Description of the motor
2.5 Selection and ordering data
1FW6 Built-in torque motors
50 Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
Order desig. / size
Rated power
loss
1)
P
V,N
in kW
External diameter
of stators
in mm
Internal diameter
of rotors
in mm
Length of
stator
in mm
Motor
mass
3)
in kg
Moment of inertia
of rotor J
L
in 10
-2
kgm
2
1FW6190-xxB05-1Jxx
3.63
502
342
110
42.8
35.8
1FW6190-xxB05-2Jxx
3.63
502
342
110
42.8
35.8
1FW6190-xxB05-5Gxx
3.63
502
342
110
42.8
35.8
1FW6190-xxB07-1Jxx
4.56
502
342
130
55.8
48.6
1FW6190-xxB07-2Jxx
4.56
502
342
130
55.8
48.6
1FW6190-xxB07-5Gxx
4.56
502
342
130
55.8
48.6
1FW6190-xxB07-8Fxx
4.71
502
342
130
55.8
48.6
1FW6190-xxB10-1Jxx
5.96
502
342
160
75.8
67.8
1FW6190-xxB10-2Jxx
5.96
502
342
160
75.8
67.8
1FW6190-xxB10-5Gxx
5.96
502
342
160
75.8
67.8
1FW6190-xxB10-8Fxx
6.14
502
342
160
75.8
67.8
1FW6190-xxB10-2Pxx
6.02
502
342
170
75.8
67.8
1FW6190-xxB15-2Jxx
8.28
502
342
210
108
99.8
1FW6190-xxB15-5Gxx
8.28
502
342
210
108
99.8
1FW6190-xxB15-8Fxx
8.53
502
342
210
108
99.8
1FW6190-xxB15-2Pxx
8.36
502
342
220
108
99.8
1FW6190-xxB15-0Wxx
8.53
502
342
220
108
99.8
1FW6190-xxB20-5Gxx
10.6
502
342
260
136
132
1FW6190-xxB20-8Fxx
10.9
502
342
260
136
132
1FW6190-xxB20-2Pxx
10.7
502
342
270
136
132
1FW6190-xxB20-0Wxx
10.9
502
342
270
136
132
1FW6230-xxB05-1Jxx
3.66
576
416
110
44.8
62.2
1FW6230-xxB05-2Jxx
3.78
576
416
110
44.8
62.2
1FW6230-xxB05-5Gxx
3.7
576
416
110
44.8
62.2
1FW6230-xxB07-1Jxx 4.6 576 416 130 58.8 84.3
1FW6230-xxB07-2Jxx 4.74 576 416 130 58.8 84.3
1FW6230-xxB07-5Gxx
4.64
576
416
130
58.8
84.3
1FW6230-xxB07-8Fxx
4.67
576
416
130
58.8
84.3
1FW6230-xxB10-2Jxx
6.19
576
416
160
81.8
118
1FW6230-xxB10-5Gxx
6.06
576
416
160
81.8
118
1FW6230-xxB10-8Fxx
6.09
576
416
160
81.8
118
1FW6230-xxB10-2Pxx
6.24
576
416
160
81.8
118
1FW6230-xxB15-4Cxx
8.66
576
416
210
118
173
1FW6230-xxB15-5Gxx
8.43
576
416
210
118
173
1FW6230-xxB15-8Fxx
8.46
576
416
210
118
173
1FW6230-xxB15-2Pxx
8.67
576
416
210
118
173
