Siemens SIMOTICS T-1FW6 Configuration Manual

Description of the motor
2.5 Selection and ordering data
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
51
Order desig. / size
Rated power
loss
1)
P
V,N
in kW
External diameter
of stators
in mm
Internal diameter
of rotors
in mm
Length of
stator
in mm
Motor
mass
3)
in kg
Moment of inertia
of rotor J
L
in 10
-2
kgm
2
1FW6230-xxB15-0Wxx
8.46
576
416
220
118
173
1FW6230-xxB20-5Gxx
10.8
576
416
260
154
228
1FW6230-xxB20-8Fxx
10.8
576
416
260
154
228
1FW6230-xxB20-2Pxx
11.1
576
416
260
154
228
1FW6230-xxB20-0Wxx
10.8
576
416
270
154
228
1FW6290-xxB07-5Gxx
5.15
730
520
140
104
228
1FW6290-xxB07-0Lxx
5.14
730
520
140
104
228
1FW6290-xxB07-2Pxx
5.18
730
520
160
104
228
1FW6290-xxB11-7Axx
7.09
730
520
180
159
334
1FW6290-xxB11-0Lxx
7.1
730
520
180
159
334
1FW6290-xxB11-2Pxx
7.15
730
520
200
159
334
1FW6290-xxB15-7Axx
9.05
730
520
220
215
440
1FW6290-xxB15-0Lxx
9.06
730
520
220
215
440
1FW6290-xxB15-2Pxx
9.11
730
520
240
215
440
1FW6290-xxB20-0Lxx
11
730
520
260
261
546
1FW6290-xxB20-2Pxx
11.1
730
520
280
261
546
1)
Water cooling with 35 °C intake temperature;
3)
Motor mass not including mass of transportation locks
