Communication
11.7 Communication services and used port numbers
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
901
Communication services and used port numbers
SINAMICS converters support the communication protocols listed in the following table. The
address parameters, the relevant communication layer, as well as the communication role
and the communication direction are decisive for each protocol. You require this information
to match the security measures for the protection of the automation system to the used
protocols (e.g. firewall). The security measures are restricted to Ethernet and PROFINET
networks.
The following table shows the various layers and protocols that are used.
(2) Link layer
(4) Transport layer
DCP
Discovery and
configuration
protocol
Not relevant
(2) Ethernet II and
IEEE 802.1Q and
Ethertype 0x8892
(PROFINET)
Accessible
nodes,
PROFINET
Discovery and
configuration
DCP is used by
PROFINET to determine
PROFINET devices and
to make basic settings.
DCP uses the special
multicast MAC address:
xx-xx-xx-01-0E-CF,
xx-xx-xx = Organization-
LLDP
Link Layer Dis-
covery protocol
Not relevant
(2) Ethernet II and
IEEE 802.1Q and
Ethertype 0x88CC
(PROFINET)
PROFINET
Link Layer
Discovery pro-
tocol
LLDP is used by
PROFINET to determine
and manage neighbor-
hood relationships be-
tween PROFINET
devices.
LLDP uses the special
multicast MAC address:
MRP
Media Redun-
dancy Protocol
Not relevant
(2) Ethernet II and
IEEE 802.1Q and
Ethertype 0x88E3
(PROFINET)
PROFINET
medium redun-
dancy
MRP enables the control
of redundant routes
through a ring topology.
MRP uses the special
multicast MAC address:
xx-xx-xx-01-15-4E,
xx-xx-xx = Organization-
ally Unique
