13.6.4
Analog outputs
Signal processing using the analog outputs is shown in the function diagrams listed below.
Properties
● Adjustable absolute-value generation
● Inversion via binector input
● Adjustable smoothing
● Adjustable transfer characteristic
● Output signal can be displayed via visualization parameter
Note
Parameters p4077 to p4080 of the scaling do not limit the voltage values / current values (for
TM31, the output can be used as current output).
Function diagrams (see SINAMICS S120/S150 List Manual)
•
9106
Terminal Board 30 (TB30)
- Analog outputs (AO 0 ... AO 1)
•
9572
Terminal Module 31 (TM31)
- Analog outputs (AO 0 ... AO 1)
