13.6 Inputs/outputs
Drive functions
970 Function Manual, 11/2017, 6SL3097-4AB00-0BP5
Fault reaction to controller failure
The onboard I/Os assigned to the controller are switched to the safe state in response to a
fault.
This also applies to terminals whose signals are transferred via the bypass channel of the
controller. This status is signaled by failure of the DO1 telegram (sign-of-life failure).
13.6.3
Analog inputs
Signal processing using the analog inputs is shown in the function diagrams listed below.
Properties
● Hardware input filter set permanently
● Simulation mode parameterizable
● Adjustable offset
● Signal can be inverted via binector input
● Adjustable absolute-value generation
● Noise suppression (p4068)
● Enabling of inputs via binector input
● Output signal available via connector output
● Scaling
● Smoothing
Note
Parameters p4057 to p4060 of th
e scaling do not limit the voltage values / current values (for
TM31, the input can be used as current input).
Analog input of Control Unit 310-2
Control Unit CU310-2 has an integrated analog input at terminal strip X131, terminals 7 and
8, an analog input. The input is preset as current or voltage input using DIP switch S5. The
input can be further differentiated using p0756 [x]:
p0756[x]
Input function
0
0...10 V
2
0...20 mA
3
4...20 mA
4
-10 V to +10 V
5
-20 mA to +20 mA
The characteristic of the analog input can be scaled using parameters p0757 to P0760.
