Name Index Description
$MN_MAX_CUTTING
_EDGE_PER_TOOL
Max. number of edges per tool
$MN_MAX_
SUMCORR_PERCUT
TING_EDGE
Max. number of total offsets per tool
$MN_MM_KIND_OF_
SUMCORR
Properties of total offsets in NCK
$MN_MM_NUM_CC_
MAGAZINE_PARAM
No. of MagAnwdat (magazine user data) parameters
for one tool magazine
$MN_MM_NUM_CC_
MAGLOC_PARAM
Number of Mag-Anwdat (magazine user data
parameters) per tool magazine location
$MN_MM_NUM_CC_
MON_PARAM
No. of monitor. user data parameters for tool edge
$MN_MM_NUM_GLO
BAL_BASE_FRAMES
Number of channel-independent basic frames
$MN_MM_NUM_
SUMCORR
Total number of total offsets in NCK
$MN_MM_NUM_
TOOL_ADAPTER
Max. no. available tool adapter data sets
$MN_MM_TOOL_MA
NAGEMENT_MASK
Settings NCK tool management
$P_UBFR[ x ,MI] x=FrameNo Mirroring of settable frame
$P_UBFR[x,RT] x=FrameNo Rotation of settable frame
$P_UBFR[x,SC] x=FrameNo Scaling factor of settable frame
$P_UBFR[x,SI] x=FrameNo Fine offset for frames
$P_UBFR[x,TR] x=FrameNo Translation of settable frame
$P_CHBFRMASK Active channel-specific basic frames
$P_EG_BC[a] EG block change criterion
$P_NCBFRMASK Active channel-independent basic frames
$P_OFFN Offset normal
$P_PFRAME [x,TR]
$P_ACTFRAME
$P_IFRAME
Or
Or
Compilation of active frame
$P_TOOL Number of active tool edge
$P_TOOLL[1] Active tool length 1
$P_TOOLL[2] Active tool length 2
$P_TOOLL[3] Active tool length 3
$P_TOOLND[x] x=ToolNo Number of cutting edges
$P_TOOLNO Number of active tool
$P_TOOLR Active tool radius
$P_UIFR[x,y,MI] x=FrameNo, y=Axis Mirroring of settable frame
$P_UIFR[x,y,RT] x=FrameNo, y=Axis Rotation of settable frame
$P_UIFR[x,y,SC] x=FrameNo, y=Axis Scaling factor of settable frame
$P_UIFR[x,y,SI] x=FrameNo, y=Axis Fine offset for frames
$P_UIFR[x,y,TR] x=FrameNo, y=Axis Translation of settable frame
$P_UIFRNUM Index of active set frame
$R[x] x=ParameterNo R parameters
$SC_PA_ACTIV_
IMMED[x]
x=Number
protection zone
Immediately active after referencing
$SC_PA_CENT_ABS
[x,0]
x=Number
protection zone
Abscissa of arc center of 1st contour element
