Siemens SINUMERIK 810D

08/2005 Online Help (HE1)
1 Programming Help
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
HE1/1-17
Extended Help
The following entries are possible in the "Extended Help" parameter:
• Editor Help
/"Pdf file name", Help ID, "search string"/
• Cycle Help
/"Pdf file name", Help ID, "search string" (file name,
Help display)/
Two commas must be placed in the "Extended Help" parameter, even if no entry is
made.
Example:
The declaration line requires, e.g. the following parameters:
m,t/14/"Pdf file name", Help ID, "search string" (file name,
Help display)/CYCLE82/drilling cycle, drilling, counterboring
The entries for the "Extended Help" parameter have the following meaning:
Pdf file name
= file from which the descriptive text is to be displayed
Help ID
= unique assignment to term for which Help is to be displayed
search string
= search string in the pdf file to be displayed in the Help text.
(file name, help display)
= name of the file that contains the Help displays and the name of the Help display
to be displayed (Æ only relevant for Cycle Help)
CYCLE82
= instruction text
Drilling cycle, boring, counterbore
= description text
Sample call:
m,t/14/"PGZ.pdf",1,"RTP"(drilling,CYC82)/CYCLE82/drilling
cycle, drilling, counterboring
Note
If you wish to access only the Pdf file, only these parameters are permissible in
the "Extended Help" section.
e.g.: m,t/14/"PGZ.pdf",1,"RTP"/CYCLE82/drilling cycle, drilling, counterboring
If you wish to display only the Help display, only these parameters are
permissible in the "Extended Help" section.
e.g.: m,t/14/(drilling,CYC82)/CYCLE82/drilling cycle, drilling, counterboring
