Online Help (HE1) 08/2005
1 Programming Help
© Siemens AG, 2005. All rights reserved
HE1/1-18 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
Instruction text
"G17" is one example of an instruction text. This text is transferred to the part
program that you are editing when you select "Transfer to the Editor".
Instruction texts can be about 12 characters in length.
Descriptive text
The descriptive text is the Help text that describes the instruction more in detail.
The length of the descriptive text is limited by the display and must not, for
example, exceed 40 characters with a standard type size of 8pt.
Multiple jumps
Multiple Help references can be stored per Help text as a ring (i.e. after the last
Help reference, the first Help reference is displayed again).
E.g.: m,t/14/"Hlp.pdf",1,"Hilfe1",,2,"Hilfe2","Help3.pdf",3,,/
CYCLE82/drilling cycle, drilling, counterboring
I.e.:
1. Entry in the Help text ring
File: HLP.PDF
Index: 1
Text: Help1
2. Entry in the Help text ring
File: HLP.PDF
Index: 2
Text: Help2
3. Entry in the Help text ring
File: HELP3.PDF
Index: 3
Text: Help2
To avoid repetitions, the components of the previous block are stored, as shown in
the example. Only whole blocks are transferred.
Note
• How the pdf files and Help files are embedded in the system is described in
Section 2.2 "Embedding PDF files in the Help system".
• Two commas must be placed in the "Extended Help" parameter, even if no
entry is made.
