08/2005 Starting Up HMI Embedded (IM2)
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/4-87
9423 MA_MAX_SKP_LEVEL
H05
CR: K1
- Max. skip levels in NC program BYTE 3/4
Adv, Emb Adv: 1, Emb: 1
1 8
Power On SW5
9424 MA_COORDINATE_SYSTEM
H05
CR: K2
- Coord. system for actual-value display
0: Work (WCS)
1: SZS (settable zero system)
BYTE 3/4
Adv, Emb Adv: 0, Emb: 0
0 1
Power On SW5
9425 MA_SCRATCH_DEFAULT_MODE
H05
CR: K2
- Tool offset calculation scratching DOUBLE 3/4
Emb Emb: 0
0 2236962
IMMEDIATE
LY
5.3
9426 MA_AX_DRIVELOAD_FROM_PLC1
H01, H02,
H05
CR:
- Machine-axis index, analog spindle power-rating display BYTE 3/4
Emb Emb: 0
0 31
Power On Emb 6.5
9427 MA_AX_DRIVELOAD_FROM_PLC2
H01, H02,
H05
CR:
- Machine-axis index, analog spindle power-rating display BYTE 3/4
Emb Emb: 0
0 31
Power On Emb 6.5
9428 MA_SPIND_MAX_POWER
H01, H02,
H05
CR: IAM4
- Maximum value of spindle display REAL 3/4
Emb Emb: 100
100 0xFFFF
Power On Emb 6.5
9429 MA_SPIND_POWER_RANGE
H01, H02,
H05
CR: IAM4
- Maximum value of spindle display REAL 3/4
Emb Emb: 100
100 0xFFFF
Power On Emb 6.5
9430 TM_UNLOAD_AND_DELETE CR: FBO
- BOOL 3/4
OP30, OP30: 0,
*** ***
Power On SW5
9431 TM_LOAD_TOOL_NEW CR: FBO
- BOOL 3/4
OP30, OP30: 1,
*** ***
Power On SW5
9432 TM_TOOL_STATE_DEF_VAL CR:
- BYTE 3/4
OP30, OP30: 2,
*** ***
Power On
9433 TM_ACT_SEARCH_AND_POS CR:
- BOOL 3/4
OP30, OP30: 0,
*** ***
Power On
9434 TM_LOAD_LOC1 CR: FBW
-
0: Autom. determination for one magazine
INTEGER 3/7
OP30, OP30: 0,
*** ***
Power On SW4.2
