Siemens SINUMERIK 810D - 6.10 Manage programs

Starting Up HMI Embedded (IM2) 08/2005
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM2/4-88 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
9435 TM_LOAD_LOC2 CR: FBW
-
0: Autom. determination for one magazine
INTEGER 3/7
OP30, OP30: 0,
*** ***
Power On SW4.2
9436 TM_LOAD_LOC3 CR: FBW
-
0: Autom. determination for one magazine
INTEGER 3/7
OP30, OP30: 0,
*** ***
Power On SW4.2
9437 TM_LOAD_LOC4 CR: FBW
-
0: Autom. determination for one magazine
INTEGER 3/7
OP30, OP30: 0,
*** ***
Power On SW4.2
9438 TM_LOAD_LOC5 CR: FBW
-
0: Autom. determination for one magazine
INTEGER 3/7
OP30, OP30: 0,
*** ***
Power On SW4.2
9440 ACTIVATE_SEL_USER_DATA
H05
CR: K2
- Activating the active wear immediately BYTE 3/4
Adv, Emb Adv: 1, Emb: 0
0 1
IMMEDIATE
LY
SW4.3
9442 MA_AUXFU_GROUPS
H01, H02,
H05
CR:
- Displayed auxiliary function groups STRING 3/7
Emb, Emb: 0
*** ***
Power On SW4.2
9450 WRITE_TOA_FINE_LIMIT
H05
CR: K2
mm Limit value for wear fine DOUBLE 3/4
Adv, Emb Adv: 0, Emb:
0.999
*** ***
IMMEDIATE
LY
SW4.2
9451 WRITE_ZOA_FINE_LIMIT
H05
CR: K2
mm Limit value for offset fine DOUBLE 3/4
Adv, Emb Adv: 0, Emb:
0.999
*** ***
IMMEDIATE
LY
SW4.2
9459 PA_ZOA_MODE
H05
CR: K2, IM2
- Display mode of work offset BYTE 3/4
Emb Emb: 1
0 1
IMMEDIATE
LY
SW 6.1
9460 PROGRAM_SETTINGS
H05
CR: A2
- Settings in the Program area INTEGER 3/4
Adv, Emb Adv: 0, Emb: 5
*** ***
IMMEDIATE
LY
SW5.1
9461 CONTOUR_END_TEXT
H05
CR: A2
- String to be added at the end of the contour STRING 3/4
Emb Emb: "
*** ***
IMMEDIATE
LY
SW5.1
9464 MAX_PROGRAMM_SIZE_CHECK
H05
CR:
- File size, as of which no check is made INTEGER 3/4
Emb Emb: 0
*** ***
IMMEDIATE
LY
SW6.4
