08/2005 Starting Up HMI Embedded (IM2)
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/4-89
9477 TO_TRACE
H01, H02,
H05
CR:
- For internal testing purposes REAL 3/4
SM, ST, Emb SM: 0, ST: 0,
Emb: 0
0 0xFFFF
Power On
9478 TO_OPTION_MASK
H01, H02,
H05
CR:
- For internal purposes INTEGER 2/2
SM, ST, Emb SM: 1, ST: 1,
Emb: 0
0 0xFFFF
Power On
9479 TO_MAG_PLACE_DISTANCE
H02, H05
CR:
mm Distance between individual magazine locations DOUBLE 3/4
ST, Emb ST: Emb: 0
0 10000
Power On SW6.3
9480 MA_SIMULATION_MODE
H05
CR:
- Simulation mode BYTE 3/4
Adv Adv: -1
-1 2
IMMEDIATE
LY
SW6.4
9481 MA_STAND_SIMULATION_LIMIT
H05
CR:
- Limit of the standard simulation in KB INTEGER 3/4
Adv Adv: 200
200 2000000
IMMEDIATE
LY
SW6.4
9500 NC_PROPERTIES
H05
CR: A2
- NC properties
Bit 0: Digital drives
Bit 1: Software startup switch
Bits 2...4: Reserved
BYTE 3/4
OP30, Emb OP30: 255, Emb:
255
0 0xFF
IMMEDIATE
LY
SW 2
9509 USER_CLASS_DIRECTORY_CHG
H04, H05
CR: FBT,
FBSP, EMB
- Protection level for network configuration BYTE 3/4
Emb Emb: 1
0 7
IMMEDIATE
LY
SW6.2
9510 USER_CLASS_DIRECTORY1_P
H04, H05
CR: A2
- Protection level for network drive 1 prog. BYTE 3/4
Adv, Emb Adv: 7, Emb: 1
0 7
IMMEDIATE
LY
SW6.1
9511 USER_CLASS_DIRECTORY2_P
H04, H05
CR: A2
- Protection level for network drive 2 prog. BYTE 3/4
Adv, Emb Adv: 7, Emb: 1
0 7
IMMEDIATE
LY
SW6.1
9512 USER_CLASS_DIRECTORY3_P
H04, H05
CR: A2
- Protection level for network drive 3 prog. BYTE 3/4
Adv, Emb Adv: 7, Emb: 1
0 7
IMMEDIATE
LY
SW6.1
9513 USER_CLASS_DIRECTORY4_P
H04, H05
CR: A2
- Protection level for network drive 4 prog. BYTE 3/4
Adv, Emb Adv: 7, Emb: 1
0 7
IMMEDIAT
ELY
6.1
