Siemens SINUMERIK 810D - Page 340

Starting Up HMI Embedded (IM2) 08/2005
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM2/4-90 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
9516 USER_CLASS_DIRECTORY1_M
H04, H05
CR: A2
- Protection level for network drive 1 mach. BYTE 3/4
Adv, Emb Adv: 7, Emb: 0
0 7
IMMEDIATE
LY
6.1
9517 USER_CLASS_DIRECTORY2_M
H04, H05
CR: A2
- Protection level for network drive 2 mach. BYTE 3/4
Adv, Emb Adv: 7, Emb: 0
0 7
IMMEDIATE
LY
6.1
9518 USER_CLASS_DIRECTORY3_M
H04, H05
CR: A2
- Protection level for network drive 3 mach. BYTE 3/4
Adv, Emb Adv: 7, Emb: 0
0 7
IMMEDIATE
LY
6.1
9519 USER_CLASS_DIRECTORY4_M
H04, H05
CR: A2
- Protection level for network drive 4 mach. BYTE 3/4
Adv, Emb Adv: 7, Emb: 0
0 7
IMMEDIATE
LY
6.1
9600 CTM_SIMULATION_DEF_X
H01, H02,
H03, H05
CR: FBMA,
FBSP
- Simulation default value for X INTEGER 3/4
SM, ST, MT,
Emb
SM: 0, ST: 0,
MT: 0, Emb: 0
-10000 10000
Power On SW2.1
(810D), 4.3
(840D)
9601 CTM_SIMULATION_DEF_Y
H01, H02,
H03, H05
CR: FBMA,
FBSP
- Simulation default value for Z INTEGER 3/4
SM, ST, MT,
Emb
SM: 0, ST: 0,
MT: 0, Emb: 0
-10000 10000
Power On SW2.1
(810D), 4.3
(840D)
9602 CTM_SIMULATION_DEF_VIS_AREA
H01, H02,
H03, H05
CR: FBMA,
FBSP
- Simulation default value for display area INTEGER 3/4
SM, ST, MT,
Emb
SM: 100, ST:
100, MT: 100,
Emb: 100
-10000 10000
Power On SW2.1
(810D), 4.3
(840D)
9603 CTM_SIMULATION_MAX_X
H01, H02,
H03, H05
CR: FBMA,
FBSP
- Simulation of maximum display X INTEGER 3/4
SM, ST, MT,
Emb
SM: 0, ST: 0,
MT: 0, Emb: 0
-10000 10000
Power On SW2.1
(810D), 4.3
(840D)
