08/2005 Starting Up HMI Embedded (IM2)
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/4-91
9604 CTM_SIMULATION_MAX_Y
H01, H02,
H03, H05
CR: FBMA,
FBSP
- Simulation maximum display Z INTEGER 3/4
SM, ST, MT,
Emb
SM: 0, ST: 0,
MT: 0, Emb: 0
-10000 10000
Power On 840D SW
4.3, 810D
SW 2.1
9605 CTM_SIMULATION_MAX_VIS_AREA
H01, H02,
H03, H05
CR: FBMA,
FBSP
- Simulation of maximum display area INTEGER 3/4
SM, ST, MT,
Emb
SM: 1000, ST:
1000, MT: 1000,
Emb: 1000
-10000 10000
Power On 840D SW4.3,
810D SW2.1
9606 CTM_SIMULATION_TIME_NEW_POS
H01, H02,
H03, H05
CR: FBMA,
FBT
- Simulation updating rate of actual value INTEGER 3/4
SM, ST, MT,
Emb
SM: 250, ST:
350, MT: 250,
Emb: 100
0 4000
Power On 840D SW4.3,
810D SW2.1,
ST SW6.1
9610 CTM_POS_COORDINATE_SYSTEM
H03, H05
CR: FBMA
- Position of coordinate system for turning BYTE 3/4
MT, Adv, Emb MT: 2, Adv: 2,
Emb: 2
0 7
IMMEDIATE
LY
840D SW4.3,
810D SW2.1
9611 CTM_CROSS_AX_DIAMETER_ON
H02, H03,
H05
CR: FBMA,
FBT
- Diameter display for active transverse axes BYTE 3/4
ST, MT, Emb ST: 1, MT: 1,
Emb: 1
0 1
IMMEDIATE
LY
840D SW4.3,
810D SW2.1,
ST 6.1
9619 CTM_G91_DIAMETER_ON
H02, H03,
H05
CR: FBMA,
FBT
- Incremental infeed BYTE 3/4
ST, MT, Emb ST: 0, MT: 0,
Emb: 1
0 1
IMMEDIATE
LY
840D SW4.3,
810D SW2.1,
ST SW6.1
9626 CTM_TRACE
H02, H03,
H05
CR: FBMA
- Test flags internal ManualTurn diagnostics REAL 3/4
ST, MT, Emb ST: 1, MT: 1,
Emb: 0
0 0xFFFF
IMMEDIATE
LY
840D SW4.3,
810D SW2.1
9632 CTM_ANGLE_REFERENCE_AXIS
H03, H05
CR: FBMA
- Angle reference axis
1: 1. Axis
2: 2. Axis
REAL 3/4
MT, Emb MT: 1, Emb: 1
0 1
IMMEDIA
TELY
840D SW4.4,
810D SW2.4
