Starting Up HMI Embedded (IM2) 08/2005
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM2/4-92 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
9650 CMM_POS_COORDINATE_SYSTEM
H01, H02,
H05
CR: FBSP,
FBT
- Position of coordinate system BYTE 3/4
SM, ST, Adv,
Emb
SM: 0, ST: 34,
Adv: 0, Emb: 0
0 47
IMMEDIA
TELY
SW4.3,
ST SW6.1
9651 CMM_TOOL_MANAGEMENT
H01, H02,
H05
CR: FBSP,
FBT
- Tool management strategy BYTE 3/4
SM, ST, Adv,
Emb
SM: 4, ST: 4,
Adv: 4, Emb: 4
1 4
Power On SW6.1,
ST SW6.1
9652 CMM_TOOL_LIFE_CONTROL
H01, H02,
H05
CR: FBSP,
FBT
- Tool monitoring BYTE 3/4
SM, ST, Adv,
Emb
SM: 1, ST: 1,
Adv: 1, Emb: 1
0 1
Power On SW6.1
9661 CMM_ENABLE_CUSTOMER_M_CODES
H01, H02,
H05
CR: FBSP
- Input of customized M commands BYTE 3/4
SM, ST, Adv,
Emb
SM: 0, ST: 0,
Adv: 4, Emb: 0
0 4
Power On 840D SW4.3,
810D SW2.3
9663 CMM_TOOL_DISPLAY_IN_DIAM
H01, H02,
H05
CR: FBSP,
FBT
- Display radius/diameter for tool BYTE 3/4
SM, ST, Adv,
Emb
SM: 1, ST: 1,
Adv: 1, Emb: 1
0 1
Power On 840D SW4.3,
810D SW2.3,
ST SW6.1
9672 CMM_FIXED_TOOL_PLACE
H01, H02,
H05
CR: FBSP,
FBT
- Fixed location coding BYTE 3/4
SM, ST, Adv,
Emb
SM: 0, ST: 1,
Adv: 0, Emb: 0
0 1
Power On 840D SW4.4,
810D SW2.4,
ST SW6.1
9673 CMM_TOOL_LOAD_STATION
H01, H02,
H05
CR: FBSP,
FBT
- Number of loading station BYTE 3/4
SM, ST, Adv,
Emb
SM: 1, ST: 1,
Adv: 1, Emb: 1
1 2
Power On 840D SW4.4,
810D SW2.4,
ST SW6.1
9674 CMM_ENABLE_TOOL_MAGAZINE
H01, H02,
H05
CR: FBSP,
FBT
- Display of magazine list BYTE 3/4
SM, ST, Adv,
Emb
SM: 1, ST: 1,
Adv: 1, Emb: 1
0 1
Power On 840D SW4.4,
810D SW2.4,
ST SW6.1
9676 CMM_DIRECTORY_SOFTKEY_PATH1
H01, H02,
H05
CR: FBSP,
FBT
- Path to the drive names in the directory man. STRING 3/4
SM, ST, Adv,
Emb
SM: ", ST: ", Adv:
", Emb: 0
*** ***
Power On 840D SW4.4,
810D SW2.4
with SM
