08/2005 Starting Up HMI Embedded (IM2)
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/4-93
9677 CMM_DIRECTORY_SOFTKEY_PATH2
H01, H02,
H05
CR: FBSP,
FBT
- Path to the drive names in the directory man. STRING 3/4
SM, ST, Adv,
Emb
SM: ", ST: ", Adv:
", Emb: 0
*** ***
Power On 840D SW4.4,
810D SW2.4
with SM
9678 CMM_DIRECTORY_SOFTKEY_PATH3
H01, H02,
H05
CR: FBSP,
FBT
- Path to the drive names in the directory man. STRING 3/4
SM, ST, Adv,
Emb
SM: ", ST: ", Adv:
", Emb: 0
*** ***
Power On 840D SW4.4,
810D SW2.4
with SM
9679 CMM_DIRECTORY_SOFTKEY_PATH4
H01, H02,
H05
CR: FBSP,
FBT
- Path to the drive names in the directory man. STRING 3/4
SM, ST, Adv,
Emb
SM: ", ST: ", Adv:
", Emb: 0
*** ***
Power On 840D SW4.4,
810D SW2.4
with SM
9900 MD_TEXT_SWITCH
H05
CR: -
- Plaintext instead of MD identifier BOOL 3/4
OP30, Adv, Emb OP30: 0, Adv: 0,
Emb: 0
*** ***
IMMEDIA
TELY
SW 2
9950 MD_NC_TEA_FILTER
H05
CR:
- Display options general machine data INTEGER 0/0
Emb Emb: 67108865
*** ***
Power On
9951 MD_NC_TEA_IDX_LIMIT
H05
CR:
- Index filter for general machine data INTEGER 0/0
Emb Emb: 0
*** ***
Power On
9952 MD_AX_TEA_FILTER
H05
CR:
- Display options axis machine data INTEGER 0/0
Emb Emb: 67108865
*** ***
Power On
9952 MD_AX_TEA_FILTER
H05
CR:
- Display options axis machine data INTEGER 0/0
Emb Emb: 67108865
*** ***
Power On
9953 MD_AX_TEA_IDX_LIMIT
H05
CR:
- Index filter for axis machine data INTEGER 0/0
Emb Emb: 0
*** ***
Power On
9954 MD_CH_TEA_FILTER
H05
CR:
- Display options channel machine data INTEGER 0/0
Emb Emb: 33554433
*** ***
Power On
9955 MD_CH_TEA_IDX_LIMIT
H05
CR:
- Index filter for channel machine data INTEGER 0/0
Emb Emb: 0
*** ***
Power On
9956 MD_DRV_TEA_FILTER
H05
CR:
- Display options drive machine data INTEGER 0/0
Emb Emb: 8388609
*** ***
Power On
9957 MD_DRV_TEA_IDX_LIMIT
H05
CR:
- Index filter for drive machine data INTEGER 0/0
Emb Emb: 0
*** ***
Power On
