Siemens SINUMERIK 810D Commissioning Manual

08/2005 Commissioning HMI Advanced (IM4)
2 Setting Functions and Parameters
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
IM4/2-27
Note
When using the "Reversible spindles" or "Axis container" functions, the spindle
status is output before the spindle reversal or assignment to axis/spindle
container, i.e. the spindle number displayed under spindle status is the "logical"
spindle.
Activation
The function is activated by MD 9052 SHOW_CHANNEL_SPANNING_STATE > 0.
Changes in MD 9052 take effect after a POWER ON.
This function is available if it is activated by means of the following machine data
element:
9052
MD number
SHOW_CHANNEL_SPANNING_STAT
Change cross-channel status display
Default value: 0 Min. input value: 0 Max. input value: 1
Changes effective after POWER ON Protection level (R/W) 4/1 Unit: -
Data type: STRING Applies from version 6.2
Meaning Cross-channel status display:
0 = Display previous program status in header
1 = Display in program status line in header according to configuration in
Header.ini file.
SINUMERIK status display
The following four predefined displays are available:
1 Channel status (active, stopped, RESET) with superimposed spindle stop
and feed stop
2 Channel status (active, stopped, RESET) with superimposed feed stop
3 Channel status (active, stopped, RESET)
4 Spindle status counterclockwise direction, clockwise direction, spindle
stop, spindle halt M05)
1 channel status
The channel status, feed stop, and spindle status are output as an icon at the
display position. The channel status icons can be superimposed with the "Spindle
not enabled" or "Feed not enabled" icon.
The following hierarchy applies (from highest to lowest priority):
1. Channel STOP (Highest priority)
2. Spindle not enabled
3. Feed is not enabled
4. Channel active
5. Channel RESET (Lowest priority)
Syntax:
ChanStatFeedStopSpindleStop = <Channel number>
Spindles = <Spindle number1>,...,<Spindle number n>
Channel number: Number of channel
