Flexible NC programming
1.17 Activate machine data (NEWCONF)
Job planning
132 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
1.17 Activate machine data (NEWCONF)
Function
The NEWCONF command is used to set all machine data of the "NEW_CONFIG" effectiveness
level active. The function can also be activated in the HMI user interface by pressing the "MD
data effective" softkey.
When the "NEWCONF" function is executed there is an implicit preprocessing stop; in other
words, path movement is interrupted.
Syntax
NEWCONF
Significance
NEWCONF: Command for setting all machine data of the "NEW_CONFIG" effectiveness
level active
Cross-channel execution of NEWCONF from the part program
If changes are made to axial machine data from the part program and then activated with
NEWCONF, NEWCONF will only activate the machine data containing changes affecting the part
program channel.
Note
In order to ensure that all changes are applied, the
NEWCONF command must be executed in
every channel in which the axes or functions affected by the changes to the machine data
are being calculated.
No axial machine data are effective for
NEWCONF.
An axial RESET must be performed for axes controlled by the PLC.
Example
Milling: Machine drill position with different technologies
Program code Comments
N10 $MA_CONTOUR_TOL[AX]=1.0 ; Change machine data.
N20 NEWCONF ; Activate machine data.
...
