User stock removal programs
15.3 Generate coded contour table (CONTDCON)
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
697
15.3 Generate coded contour table (CONTDCON)
Function
With the contour preparation activated with CONTDCON, the following NC blocks that are called
are saved in a coded form in a 6-column contour table to optimize memory use. Each
contour element corresponds to one row in the contour table. When familiar with the coding
rules specified below, e.g., you can combine DIN code programs for cycles from the table
lines. The data of the output point are saved in the table line with the number 0.
Syntax
Activate contour preparation:
CONTDCON(<contour table>,<machining direction>)
Deactivate contour preparation and return to the normal execution mode:
EXECUTE(<ERROR>)
See " Deactivate contour preparation (EXECUTE) "
Significance
CONTDCON
Command to activate the contour preparation to
generate a coded contour table
<contour table>
Names of contour table
Parameter for machining direction
Type: INT
0 Contour preparation according to
the sequence of contour blocks
(default value)
<machining direction>
Value:
1 Not permissible
Note
The G codes permitted for
CONTDCON in the program section to be included in the table are
more comprehensive than for
CONTPRON. Further, feed rates and feed rate type are saved for
each contour section.
