Motion synchronous actions
10.4 Actions in synchronized actions
Job planning
574 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
10.4 Actions in synchronized actions
10.4.1 Overview of possible actions in synchronized actions
Actions in synchronized actions consist of value assignments, function or parameter calls,
keywords or technology cycles. Complex executions are possible using operators.
Possible applications include:
● Calculations of complex expressions in the IPO cycle
● Axis movements and spindle controls
● Setting data from synchronized actions can be changed and evaluated online (e.g. output
positions and times of software cams at the PLC or NC I/O)
● Output of auxiliary functions to PLC
● Set-up additional safety functions
● Set superimposed movement, online tool offset and clearance control
● Execute actions in all operating modes
● Influence synchronized actions from PLC
● Run technology cycles
● Output of digital and analog signals
● Record performance recording of the synchronized actions at the interpolation cycle and
the computation time of the position controller for the loading report
● Diagnostic capabilities in the user interface
Synchronized action Description
DO $V…=
DO $A...=
Assign variable (servo-values)
Assign variable (main-run variable)
DO $AC…[n]=
DO $AC_MARKER[n]=
DO $AC_PARAM[n]=
Special main run variable
Read or write synchronized action markers
Read or write synchronized action parameters
DO $R[n]= Read or write arithmetic variable
DO $MD...=
DO $$SD...=
Read MD value at the interpolation instant in time
Writing SD value in the main run
DO $AC_TIMER[n]=Start value Timers
DO $AC_FIFO1[n] …FIFO10[n]= FIFO variables
DO $AC_BLOCKTYPE=
DO $AC_BLOCKTYPEINFO=
DO $AC_SPLITBLOCK=
Interpret the current block (main run variable)
DO M-, S and H e.g. M07 Output of M, S and H auxiliary functions
DO RDISABLE Set read-in disable
DO STOPREOF Cancel preprocessing stop
DO DELDTG Fast deletion of distance-to-go without preprocessing
stop
