File and Program Management
2.1 Program memory
Job planning
208 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Standard directories
Its standard complement of directories is as follows:
Folder Contents
_N_DEF_DIR Data modules and macro modules
_N_CST_DIR Standard cycles
_N_CMA_DIR Manufacturer cycles
_N_CUS_DIR User cycles
_N_WKS_DIR Workpieces
_N_SPF_DIR Global subprograms
_N_MPF_DIR Main programs
_N_COM_DIR Comments
File types
The following file types can be stored in the main memory:
File type Description
name_MPF Main program
name_SPF Subprogram
name_TEA Machine data
name_SEA Setting data
name_TOA Tool offsets
name_UFR Zero offsets/frames
name_INI Initialization files
name_GUD Global user data
name_RPA R parameters
name_COM Comment
name_DEF Definitions for global user data and macros
Workpiece main directory (_N_WKS_DIR)
The workpiece main directory exists in the standard setup of the program memory under the
name
_N_WKS_DIR. The workpiece main directory contains all the workpiece directories for the
workpieces that you have programmed.
Workpiece directories (..._WPD)
To make data and program handling more flexible certain data and programs can be
grouped together or stored in individual workpiece directories.
A workpiece directory contains all files required for machining a workpiece. These can be
main programs, subprograms, any initialization programs and comment files.
The first time a part program is started, initialization programs are executed once, depending
on the selected program (in accordance with machine data MD11280
$MN_WPD_INI_MODE).
