Motion synchronous actions
10.3 Main run variables for synchronized actions
Job planning
564 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Significance
PROC
Subprogram definition
UP
Subprogram name for recognition
PARn
Parameter n
NO_AXIS
Initialization of formula parameter with default axis identifier
Example: Definition of axis variables in the main program
Program code
DEF AXIS AXVAR
UP( , AXVAR)
10.3.5 Synchronized action marker ($AC_MARKER[n])
Function
The array variable $AC_MARKER[n] can be read and written in synchronized actions. These
variables can either be saved in the memory of the active or passive file system.
Synchronized action variable: Data type INT
$AC_MARKER[n] Channel-specific marker/counter, INTEGER data type
$MC_MM_NUM_AC_MARKER Machine data for setting the number of channel-
specific markers for movement synchronized actions
n Array index of variables 0-n
Example of reading and writing marker variables
Program code
WHEN ... DO $AC_MARKER[0] = 2
WHEN ... DO $AC_MARKER[0] = 3
WHENEVER $AC_MARKER[0] == 3 DO $AC_OVR=50
