Tool offsets

7.6 Tool orientation (ORIC, ORID, OSOF, OSC, OSS, OSSE, ORIS, OSD, OST)

Job planning

Programming Manual, 07/2010, 6FC5398-2BP40-0BA0

423

7.6 Tool orientation (ORIC, ORID, OSOF, OSC, OSS, OSSE, ORIS,

OSD, OST)

Function

The term tool orientation describes the geometric alignment of the tool in space. The tool

orientation on a 5-axis machine tool can be set by means of program commands.

'LUHFWLRQYHFWRU

;

Orientation rounding movements activated with

OSD and OST are formed differently depending

on the type of interpolation for tool orientation.

If vector interpolation is active, the smoothed orientation characteristic is also interpolated

using vector interpolation. On the other hand, if rotary axis interpolation is active, the

orientation is smoothed directly using rotary axis movements.
