Flexible NC programming

1.25 Subprogram technique

Job planning

Programming Manual, 07/2010, 6FC5398-2BP40-0BA0

165

Example 4: Is not stopped with MD10702 Bit 12 = 1

Initial situation:

● Single block execution is active.

● MD10702 $MN_IGNORE_SINGLEBLOCK_MASK Bit12 = 1

Main program:

Program code Comments

N10 G0 X0 ; Stop in this part program line.

N20 X10 ; Stop in this part program line.

N30 CYCLE ; Traversing block generated by the cycle.

N50 G90 X20 ; Stop in this part program line.

M30

Cycle CYCLE:

Program code Comments

PROC CYCLE SBLOF ; Suppress single block stop:

N100 R0 = 1

N110 SBLON ; Execution is not stopped in the part program line due

to the fact that MD10702 bit12=1.

N120 X1 ; Execution is stopped in this part program line.

N140 SBLOF

N150 R0 = 2

RET
