Siemens SINUMERIK 828D Programming Manual

Flexible NC programming
1.25 Subprogram technique
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
169
Examples
Example 1: Suppress current block display in the cycle
Program code Comments
PROC CYCLE (AXIS TOMOV, REAL POSITION) SAVE DISPLOF ; Suppress current block display
Instead, the cycle call should be
displayed, e.g.: CYCLE(X,100.0)
DEF REAL DIFF ; Cycle contents
G01 ...
...
RET ; Subprogram return jump. The block
following the cycle call is
displayed in the block display.
Example 2: Block display for alarm output
Subprogram SUBPROG1 (with
ACTBLOCNO):
Program code Comments
PROC SUBPROG1 DISPLOF ACTBLOCNO
N8000 R10 = R33 + R44
...
N9040 R10 = 66 X100 ; Output Alarm 12080
...
N10000 M17
Subprogram SUBPROG2 (without
ACTBLOCNO):
Program code Comments
PROC SUBPROG2 DISPLOF
N5000 R10 = R33 + R44
...
N6040 R10 = 66 X100 ; Output Alarm 12080
...
N7000 M17

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
