Special Motion Commands
4.8 Extended measuring function (MEASA, MEAWA, MEAC) (option)
Job planning
264 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Note
MEASA and MEAWA are non-modal; they can be programmed together in one block. However, if
MEASA/MEAWA is programmed together with MEAS/MEAW in the same block, an error message is
output.
Significance
Command: Axial measurement with deletion of distance-to-go
MEASA
Effective: non-modal
Command: Axial measurement without deletion of distance-to-go
MEAWA
Effective: non-modal
Command: Continuous axial measurement without deletion of
distance-to-go
MEAC
Effective: non-modal
<axis>
Name of channel axis used for measurement
Two-digit number indicating the operating mode (measuring
mode and measuring system)
Measuring mode(units decade):
0 Cancel measuring task.
1 Up to 4 different trigger events can be activated
simultaneously.
2 Up to 4 trigger events can be activated consecutively.
3 Up to 4 trigger events can be activated consecutively, but
with no monitoring of trigger event 1 on START (alarms
21700/21703 are suppressed).
Note:
This mode is not supported by
MEAC.
Measuring system (tens decade):
0 (or no data) Active measuring system
1 Measuring system 1
2 Measuring system 2
<mode>
3 Both measuring systems
Trigger event to initiate measurement
Type: INT
Range of values: -2, -1, 1, 2
Significance:
(+)1 Rising edge of probe 1
-1 Falling edge of probe 1
(+)2 Rising edge of probe 2
<TE>
-2 Falling edge of probe 2
<measurement memory>
Number of FIFO (circulating storage)
