Siemens SINUMERIK 828D Programming Manual

Coordinate transformation (FRAMES)
5.5 Preset offset (PRESETON)
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
297
Example
Geometry axis: A, associated machine axis: X1
Program code Comment
N10 G0 A100 ; Axis A travels to position 100
N20 PRESETON(X1,50) ; At position 100, machine axis X1 receives the new
actual value 50 => new actual value display:
- axis X1, MCS: 50
- Axis A, WCS: 50
N30 A100 ; Axis A travels 50 mm to position 100

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
