Coordinate transformation (FRAMES)
5.6 Frame calculation from three measuring points in space (MEAFRAME)
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
301
Program code Comments
N700 G500
; Deactivate settable frame
s with
zero frame (no value entered,
pre-assigned).
No_FRAME ; Deactivate settable frame, as
pre-assigned with zero frame (no
value entered).
M0
M30
Example of concatenating frames
Chaining of MEAFRAME for offsets
The
MEAFRAME( ) function provides an offset frame. If this offset frame is concatenated with a
set frame
$P_UIFR[1] that was active when the function was called, e.g., G54, one receives a
settable frame for further conversions for the procedure or machining.
Concatenation with ADDFRAME
If you want this offset frame in the frame chain to apply at a different position or if other
frames are active before the settable frame, the
ADDFRAME( ) function can be used for
chaining into one of the channel basic frames or a system frame.
The following must not be active in the frames:
● Mirroring with
MIRROR
● Scaling with
SCALE
The input parameters for the setpoints and actual values are the workpiece coordinates.
These coordinates must always be specified
● metrically or in inches
(G71/G70) and
● with reference to the radius
(DIAMOF)
in the basic system of the controller.
