Path traversing behavior
8.4 Conditionally interruptible program sections (DELAYFSTON, DELAYFSTOF)
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
471
Overlapping/nesting:
If two stop delay sections overlap, one from the NC commands and the other from machine
data
MD 11550: STOP_MODE_MASK, the largest possible stop delay section will be generated.
The following features regulate the interaction between NC commands
DELAYFSTON and
DELAYFSTOF with nesting and end of subroutine:
1.
DELAYFSTOF is activated implicitly at the end of the subroutine in which DELAYFSTON is
called.
2.
DELAYFSTON stop delay section has no effect.
3. If subroutine 1 calls subroutine 2 in a stop delay section, the whole of subroutine 2 is a
stop delay section.
DELAYFSTOF in particular has no effect in subroutine 2.
Note
REPOSA is an end of subroutine command and
DELAYFSTON is always deselected.
If a "hard" stop event coincides with the "stop delay section", the entire "stop delay
section" is deselected! Thus, if any other stop occurs in this program section, it will be
stopped immediately. A new program setting (new
DELAYFSTON) must be made in order to
start a new stop delay section.
If the Stop key is pressed before the stop delay section and the NCK must travel into the
stop delay section for braking, the NCK will stop in the stop delay section and the stop
delay section will remain deselected!
A stop delay section entered with an override of 0% will not be accepted!
This applies to all "soft" stop events.
STOPALL can be used to decelerate in the stop delay section. A STOPALL, however,
immediately activates all other stop events that were previously delayed.
System variables
A stop delay section can be detected in the parts program with $P_DELAYFST. If bit 0 of the
system variables is set to 1, parts program processing is now in a stop delay section.
A stop delay section can be detected in synchronized actions with
$AC_DELAYFST. If bit 0 of
the system variables is set to 1, parts program processing is now in a stop delay section.
Compatibility
Default of machine data MD 11550: STOP_MODE_MASK Bit 0 = 0 triggers implicit stop delay
section during a G code group
G331/G332 and when a path movement or G4 is programmed.
Bit 0 = 1 permits a stop during a G code group
G331/G332 and when a path movement or G4
has been programmed (behavior until SW 6). The DELAYFSTON/DELAYFSTOF commands must
be used to define a stop delay section.
