Axis couplings
9.2 Curve tables (CTAB)
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
509
Significance
CTABDEL
Command for deleting curve tables
<n>
Number (ID) of the curve table to be deleted
When a curve table range
CTABDEL(<n>,<m>) is deleted, <n> is used
to specify the number of the first curve table in the range.
<m>
When a curve table range
CTABDEL(<n>,<m>) is deleted, <m> is used
to specify the number of the last curve table in the range.
<m> has to be greater than <n>.
Specification of memory location (optional)
In the case of deletion without a memory location being specified,
the specified curve tables are deleted in the static and the dynamic
NC memory.
In the case of deletion with a memory location being specified, of the
specified curve tables, only those located in the specified memory
location are deleted. The rest are retained.
"SRAM"
Deletion in the static NC memory
<memory location>
"DRAM"
Deletion in the dynamic NC memory
If
CTABDEL is programmed without specification of the curve table to be deleted, then all curve
tables or all curve tables in the specified memory will be deleted:
CTABDEL ()
Deletes all curve tables in the static and the dynamic NC
memory
CTABDEL(,,"SRAM")
Deletes all curve tables in the static NC memory
CTABDEL(,,"DRAM")
Deletes all curve tables in the dynamic NC memory
Note
If, in the case of multiple deletion with
CTABDEL(<n>,<m>) or CTABDEL(), at least one of the of
the curve tables to be deleted is active in a coupling, the delete command will not be
executed; in other words, none of the addressed curve tables will be deleted.
