Axis couplings
9.2 Curve tables (CTAB)
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
517
CTAB with non-periodic curve tables
If the specified
<master value> is outside the definition range, the upper or lower limit will be
output as the following value:
//
)
)
'HILQLWLRQUDQJH
0DVWHU
YDOXH
6ODYHYDOXH
CTAB with periodic curve tables
If the specified
<master value> is outside the definition range, the master value is evaluated
modulo of the definition range and the corresponding following value is output:
/
)
'HILQLWLRQUDQJH
0DVWHU
YDOXH
6ODYHYDOXH
