Motion synchronous actions
10.4 Actions in synchronized actions
Job planning
580 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Example of fast deletion of distance-to-go path
Program code Comments
WHEN $A_IN[1]==1 DO DELDTG
N100 G01 X100 Y100 F1000 ; If the input is set, motion is
interrupted
N110 G01 X…
IF $AA_DELT>50…
Example of fast axial deletion of distance-to-go
Program code Comments
Cancelation of a positioning movement:
ID=1 WHEN $A_IN[1]==1 DO MOV[V]=3 FA[V]=700 ; Start axis
WHEN $A_IN[2]==1 DO DELDTG(V) ; Delete distance-to-go, the axis
is stopped using MOV=0
Delete distance-to-go depending on the input
voltage:
WHEN $A_INA[5]>8000 DO DELDTG(X1) ; As s
on as the voltage at input 5
exceeds 8V, delete distance-to-
o
for axis X1.
Path motion continues.
POS[X1]=100 FA[X1]=10 G1 Z100 F1000
Further Information
At the end of a traversing block in which a prepared delete distance-to-go was triggered,
preprocess stop is activated implicitly.
Continuous path mode or positioning axis movements are therefore interrupted or stopped at
the end of the block with fast delete distance-to-go.
Note
Prepared delete distance-to-go:
• cannot be used with active tool radius correction.
• the action must only be programmed in non modal synchronized actions (without ID
number).
