Motion synchronous actions
10.4 Actions in synchronized actions
Job planning
588 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Main program "MAIN"
Program code Comment
AON ; Clearance control on
...
G1 X100 F1000
AOFF ; Clearance control off
M30
Further information
Position offset in the basic coordinate system
Using the system variable $AA_OFF[axis] motion can be superimposed on every axis in the
channel. It acts as a position offset in the basic coordinate system.
The position offset programmed in this way is overlaid immediately in the axis concerned,
whether the axis is being moved by the program or not.
Limit main run variable output:
It is possible to limit the absolute value to be corrected (main run variable output) to the
value saved in the setting data SD43350 $SA_AA_OFF_LIMIT.
The type of superimposition of the clearance is defined using machine data MD36750
$MA_AA_OFF_MODE:
Value Significance
0 Proportional evaluation
1 Integrating evaluation
Using the system variable $AA_OFF_LIMIT[axis] it can be interrogated, dependent on the
direction, whether the correction value is within the limit range. The system variable can be
interrupted from synchronized actions and when a limit value is reached, can be used to e.g.
stop the axis or set an alarm.
0: Offset value not in range
1: Limit of offset value reached in the positive direction
-1: Limit of offset value reached in the negative direction
