Punching and nibbling
12.1 Activation, deactivation
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
651
Punching and nibbling on the spot
A stroke is initiated only if the block contains traversing information for the punching or
nibbling axes (axes in active plane).
However, to initiate a stroke at the same position, one of the punching/nibbling axes can be
programmed with a traversing path of 0.
Machining with rotatable tools
Note
Use the tangential control function if you wish to position rotatable tools at a tangent to the
programmed path.
Use of M commands
As in earlier versions, macro technology allows special M functions to be used instead of
language commands (compatibility). The M functions and equivalent language commands as
used in earlier systems are as follows:
M20, M23
≙
SPOF
M22
≙
SON
M25
≙
PON
M26
≙
PDELAYON
Example for macro file:
Program code Comment
DEFINE M25 AS PON ; Punching on
DEFINE M125 AS PONS ; Punching with leader on
DEFINE M22 AS SON ; Nibbling on
DEFINE M122 AS SONS ; Nibbling with leader on
DEFINE M26 AS PDELAYON ; Punching with delay on
DEFINE M20 AS SPOF ; Punching/nibbling off
DEFINE M23 AS SPOF ; Punching, nibbling off
Programming example:
Program code Comment
...
N100 X100 M20 ; Position without punch initiation.
N110 X120 M22 ; Activate nibbling, initiate stroke before and
after motion,
N120 X150 Y150 M25 ; Activate punching, initiate stroke at end of
motion.
...
