Tables
16.1 Instructions
Job planning
720 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
CTABSSV Returns the initial value of the following
axis of a segment of the curve table
PGAsl
Read curve table values (CTABTSV, CTABTEV,
CTABTSP, CTABTEP, CTABSSV, CTABSEV, CTAB,
CTABINV, CTABTMIN, CTABTMAX) (Page 513)
CTABTEP Returns the value of the leading axis at
curve table end
PGAsl
Read curve table values (CTABTSV, CTABTEV,
CTABTSP, CTABTEP, CTABSSV, CTABSEV, CTAB,
CTABINV, CTABTMIN, CTABTMAX) (Page 513)
CTABTEV Returns the value of the the following
axis at curve table end
PGAsl
Read curve table values (CTABTSV, CTABTEV,
CTABTSP, CTABTEP, CTABSSV, CTABSEV, CTAB,
CTABINV, CTABTMIN, CTABTMAX) (Page
513)
CTABTMAX Returns the maximum value of the
following axis of the curve table
PGAsl
Read curve table values (CTABTSV, CTABTEV,
CTABTSP, CTABTEP, CTABSSV, CTABSEV, CTAB,
CTABINV, CTABTMIN, CTABTMAX) (Page 513)
CTABTMIN Returns the minimum value of the
following axis of the curve table
PGAsl
Read curve table values (CTABTSV, CTABTEV,
CTABTSP, CTABTEP, CTABSSV, CTABSEV, CTAB,
CTABINV, CTABTMIN, CTABTMAX) (Page 513)
CTABTSP Returns the value of the leading axis at
curve table start
PGAsl
Read curve table values (CTABTSV, CTABTEV,
CTABTSP, CTABTEP, CTABSSV, CTABSEV, CTAB,
CTABINV, CTABTMIN, CTABTMAX) (Page 513)
CTABTSV Returns the value of the following axis at
curve table start
PGAsl
Read curve table values (CTABTSV, CTABTEV,
CTABTSP, CTABTEP, CTABSSV, CTABSEV, CTAB,
CTABINV, CTABTMIN, CTABTMAX) (Page 513)
CTABUNLOCK Revoke delete and overwrite lock PGAsl
Locking curve tables to prevent deletion and
overwriting (CTABLOCK, CTABUNLOCK)
(Page 510)
CTOL Contour tolerance for compressor
functions, orientation smoothing and
smoothing types
PGAsl
Programmable contour/orientation tolerance (CTOL,
OTOL, ATOL) (Page
490)
CTRANS Zero offset for multiple axes PGAsl
Coarse and fine offsets (CFINE, CTRANS)
(Page
293)
CUT2D
3)
2D tool offset m PGsl
CUT2DF 2D tool offset The tool offset is applied
relative to the current frame (inclined
plane).
m PGsl
CUT3DC 3D tool offset circumferential milling m PGAsl
Activate 3D tool offsets (CUT3DC..., CUT3DF...)
(Page 409)
