Siemens SIPROTEC 4 7SJ61 User Manual

Addr. Parameter Setting Options Default Setting Comments
170 50BF Disabled
Enabled
enabled w/ 3I0>
Disabled 50BF Breaker Failure Protection
171 79 Auto Recl. Disabled
Enabled
Disabled 79 Auto-Reclose Function
172 52 B.WEAR MONIT Disabled
Ix-Method
2P-Method
I2t-Method
Disabled 52 Breaker Wear Monitoring
182 74 Trip Ct Supv Disabled
2 Binary Inputs
1 Binary Input
Disabled 74TC Trip Circuit Supervision
190 RTD-BOX INPUT Disabled
Port C
Disabled External Temperature Input
191 RTD CONNECTION 6 RTD simplex
6 RTD HDX
12 RTD HDX
6 RTD simplex Ext. Temperature Input Connec-
tion Type
- FLEXIBLE FCT. 1...20 Flexible Function 01
Flexible Function 02
Flexible Function 03
Flexible Function 04
Flexible Function 05
Flexible Function 06
Flexible Function 07
Flexible Function 08
Flexible Function 09
Flexible Function 10
Flexible Function 11
Flexible Function 12
Flexible Function 13
Flexible Function 14
Flexible Function 15
Flexible Function 16
Flexible Function 17
Flexible Function 18
Flexible Function 19
Flexible Function 20
Please select Flexible Functions 1...20
Functions, Settings, Information
F.1 Functional Scope
SIPROTEC 4, 7SJ61, Manual 385
C53000-G1140-C210-6, Edition 05.2016
