Simplex 4100 Operator's Manual

9-8
Press the <FUNC> key to obtain the next display:
Device Address: 3-1
Mapnet Device: M1-1
Press the <NEXT> key to obtain the next display:
F1-Force on card LED Type: Mapnet 1
MAPNET CARD
Pressing function key <F1> will turn on the LED indicator on the MAPNET Card in the FIP
control rack as long as the function key is depressed. Press the <NEXT> key to move onto the
next display.
F1-Force on device LED Type: PVPHOTO
Variable Sense PHOTO with Sounder
Pressing function key <F1> will turn on the LED indicator on the selected smoke detector and
as long as the function key is depressed. Press the <NEXT> key to move onto the next
display.
Level 3 - Room 74
Smoke Detector ON-LINE
Press the <NEXT> key to move onto the next display to verify correct device type:
Level 3 - Room 74
Smoke Detector Correct Device
Press the <NEXT> key to display the current selected sensitivity
Level 3 - Room 74
Present Sensitivity Selected - 3.7% Smoke
Continued on next page
Displaying MAPNET Device Status, Continued
TrueAlarm Sensor
Display Values,
(continued)
