Using charts | 23
Medium
This is the minimum information sufficient for navigation.
Full
This is all available information for the chart in use.
Chart categories
This option enables you to select which chart categories you want to display on your
chart.
Chart imagery style
The charts can be displayed in two different imagery styles.
2D presents chart information in a basic mapping mode, while the shaded relief option
presents chart including terrain information.
2D Shaded relief
Chart overlay
Radar and weather information can be displayed as overlay on your chart panel.
When one of the overlay options are selected the chart context menu will be expanded to
include basic function for the selected overlay.
Radar and weather functions are described in separate sections in this manual.
Chart data
The NSE system can use Insight and Navionics chart databases.
The Navionics chart includes options that not are available in the
Simrad database. Navionics options are described in the following
sections.
MENU WIN
MENU WIN
x2
